Central control for Blizzard, Pasat,Bora

Central control can control the operation of multiple air conditioners and exhaust fans. The integrated system allows modulation of the speed of devices, switching on / off depending on the set temperature limit and air humidity inside the facilities. The system as a whole consists of: a central unit, hubs (max 15), a temperature and humidity sensor and exhaust fan controllers (max 10). The whole device can be connected to the popular Modbus system, allowing, for example, to control and track system operating parameters from a personal computer.

The control is compatible with the series air conditioners: Blizzard and Pasat.

Equipment description:
1. The central unit is used to program the operation of all air conditioners and exhaust fans.
2. Hubs branch the signal from the central unit to individual air conditioners. One hub can split the signal into 4 air conditioners. The maximum number of hubs is 15, i.e. 60 air conditioners can be controlled by means of Central Control.
3. The temperature and humidity sensor makes it possible to read these values ​​in the place where the sensor is installed automatically by the central unit
. 4. The fan controllers are used to switch on the exhaust fans. Their speeds can be modulated - then it is recommended to use several drivers.


The price includes only the central unit. Additional equipment is selected depending on the project requirements.
