Indirect combined evaporative cooler KPH 10/2000

INDIRECT EVAPORATORY (ADIABATIC) SERIAL An

Indirect evaporative cooler uses a small amount of electricity to cool the air, with dry air and water.
The air is cooled in two parts of the device: in the first part, the air is cooled in an exchanger in which the dry air channels transfer heat to the wet area through a water-impermeable membrane. In the second part, the air is cooled in contact with the water via a cooling pad, where the air is slightly humidified. Here it reaches a temperature below the wet bulb temperature, around the dew point temperature.
Thanks to the use of a special heat exchanger design, the intermediate series air conditioner
 achieves high cooling efficiency. At a dry bulb air temperature of 38 ° C and humidity of 28% RH, it lowers the air temperature by 15 ° C to 23 °
C. Direct and indirect evaporative cooling technology is classified as renewable energy sources (RES)

Properties of series indirect evaporative air conditioner
1. High efficiency - EER / COP 52
2. The system can work efficiently even at 50 ° Celsius (ambient temperature).
3. As the ambient temperature rises, the cooling capacity of the air conditioner increases.
4. Wet bulb efficiency greater than 120%
. 5. Easy operation.
6. Automatic control.
7. Environmentally friendly
8. Patented modern method of operation.

Application of indirect
 air conditioners Evaporative air conditioners are used for ventilation and air cooling in rooms:
- plastics production plants: injection plants, film production
- drug warehouses
- logistic and distribution centers - data centers
, telephone exchanges
- printing houses for air cooling and humidification.
- plants manufacture of confectionery, beverages, beer (breweries)
- factories manufacturing electronics, automobiles
- computer shops
- garages, paint shops
- bakeries, pastry shops, pastry shops
- tents fair, catering, exhibition
- restaurants, restaurants, bars, homes wedding

table capacity of the air conditioner intermediate serial.
