Indirect inter-cross evaporative cooler KPK 10/2000

ADIABATIC CROSS COOLER The

Indirect evaporative cooler uses a small amount of electricity to cool the air, with dry air and water.

The heart of the indirect cross flow evaporative air conditioner is the heat exchanger, thanks to which the cooling air does not come into contact with the water. The cross-flow heat exchanger combines the advantages of cheap and effective cooling of direct air conditioners and at the same time eliminates the need for large air changes. Cross flow indirect air conditioners are used where humidity needs to be kept low.

Thanks to the use of a special heat exchanger design, the intermediate series air conditioner achieves high cooling efficiency. At a dry bulb air temperature of 38ºC and a humidity of 28%, RH lowers the air temperature by 15ºC to the level of 23ºC.

The technology of direct and indirect evaporative cooling is classified as renewable energy sources (RES).

Properties of the indirect cross evaporative air conditioner
1. High efficiency - EER / COP 27
2. The system can work efficiently even at 50 ° Celsius (ambient temperature).
3. As the ambient temperature rises, the cooling capacity of the air conditioner increases.
4. Wet bulb efficiency greater than 120%
. 5. Easy operation.
6. Automatic control.
7. Environmentally friendly
8. Patented modern method of operation.

Application of indirect
air conditioners Evaporative air conditioners are used for ventilation and air cooling in rooms:
- plastics production plants: injection plants, film production
- drug warehouses
- logistic and distribution centers - data centers
, telephone exchanges
- printing houses for air cooling and humidification.
- plants manufacture of confectionery, beverages, beer (breweries)
- factories manufacturing electronics, automobiles
- computer shops
- garages, paint shops
- bakeries, pastry shops, pastry shops
- tents fair, catering, exhibition
- restaurants, restaurants, bars, homes wedding

table capacity of the air conditioner intermediate cross.
